EGH20SA Linear Guide
This linear guide block EGH15CA is EC series, it offers a low profile, high load capacity, and high rigidity.It also features an equal load rating in all four directions and self-aligning capability to take in installation error, allowing for higher accuracies. Additionally, the lower assembly height and the shorter length make the EG series greater suitable for high-speed, automation machines and applications the place space is limited. The retainer is designed to hold the balls in the block even when it is eliminated from the rail.
Product Introduction
Description
Block types
OUR offers two types of linear guideways, flange and rectangular types.
Features of EG Series
The design of the EG series offers a low profile, high load capacity, and high rigidity. It additionally elements an equal load rating in all four directions and self-aligning capability to absorb installation-error, allowing for higher accuracies. Additionally, the lower assembly height and the shorter length make the EG series more suitable for high-speed, automation machines and applications the place space is limited.
The retainer is designed to hold the balls in the block even when it is eliminated from the rail.
Accuracy
The accuracy of the EG series can be classified into 5 classes: normal(C), high(H), precision(p), super precision(sp), and ultra precision(Up). Choose the classification by referencing the accuracy of selected equipment.
Mounting location
The standard location of the grease fitting is at both ends of the block, the nipple can also be set up in the aspect or top of the block. for lateral installation, we recommend that the nipple be mounted to the non-reference side, in any other case please contact us. When lubricating from above, in the recess for the O-ring, a smaller, preformed recess can be found. preheat the 0.8 mm diameter steel tip. Carefully open the small recess with the metal tip and pierce through it. Insert a round sealing ring into the recess. (The spherical sealing ring is not supplied with the block) Do now not open the small recess with a drill bit this may additionally introduce the danger of contamination. It is possible to carry out the lubrication by using the oil-piping joint.
|
Product Information |
|
|
Product Name |
EGH20SA Linear Guide |
|
Material |
Bearing steel, Gcr15, stainless steel, chrome steel |
|
Length |
Can be customized according to customers requirement |
|
Precision |
P0(ABEC1), P6(ABEC3), P5(ABEC5), P4(ABEC7), P2(ABEC9) |
|
Vibration & Noisy |
Z1, Z2, Z3, V1, V2, V3 |
|
Model No. |
EGH15SA, EGH15CA, EGH20SA, EGH20CA,EGH25SA, EGH25CA,EGH30SA, EGH30CA,EGH35SA, EGH35CA |
|
Our Services |
According to drawings or samples for our customers to manufacture products. We can support OEM/ODM services. |
|
Product Package |
a. Plastic bag with box case or wooden case. We can provide shipping information to our customer at any time. |
|
Delivery Time |
3~5 days for sample order, 7~10 days for small order, 10~20 days for bulk order. It depends on the actual shipping situation. |
