Ball Screw Linear Module X Y Z Axial
Our mian products consists of Linear sliding table, automatic transmission componebts. Our products have been considerably used in electronics, laser processing, welding industry, LCD, LED, PCD, Car, photoeletric
Product Introduction
Description
Our mian products consists of Linear sliding table, automatic transmission componebts. Our products have been considerably used in electronics, laser processing, welding industry, LCD, LED, PCD, Car, photoeletric, Semiconductor industries, especially have advantsges in precision positioning, dispensing, workpiece clamping, handling, positioning and assembly, visual and radiographic testing, XYZ axis movement in mechanical equipment, metal sheet cutting equipment, welding, automatic up-down material for CNC equipment Ect.
Product Details
Stacking method: It is possible to stack horizontal cross, gantry, triaxial and quadruple multiple stacking methods. The size that is not in the choice can be custom-made by contacting customer service.
Product Description
1. High pressure and heavy load
2. Smooth running, low noise and non-pollution,high speed
3. High accurancy and easy setting up
4. Trial order is accpetable
Features
Linear bearings and guides provide low friction, smooth, accurate motion for almost any moment or normal loading condition.
1. Dynamic and static friction resistance difference is small, which is helpful to improve the response speed and sensitivity of CNC system
2. The driving power is small which reduces the energy consumption
3. High positioning accuracy and repeat positioning ccuracy
4. By increasing the preload, the rigidity is greatly more suitable
5. Using paired guide rails, it has the effect of homogenizing error
|
Product Information |
|
|
Product Name |
Ball Screw Linear Module X Y Z Axial |
|
Material |
bearing steel guide, bearing steel aluminum base |
|
Stroke Range (mm) |
100-800 |
|
Model No. |
YR-MGNS100F |
|
Maximum Payload |
Horizontal(kg): 40, 35, 30, 25 Vertical(kg): 30, 25, 20, 15 |
|
Positioning accuracy(mm) |
±0.02 |
|
Length |
Can be customized according to customers requirement |
|
Product Features |
Ease of maintenance, Low production cost, Long strokes, Multiple motor configurations, Quiet and smooth movement |
|
Our Services |
According to drawings or samples for our customers to manufacture products. We can support OEM/ODM services. |
|
Product Package |
a. Plastic bag with box case or wooden case. We can provide shipping information to our customer at any time. |
|
Delivery Time |
3~5 days for sample order, 7~10 days for small order, 10~20 days for bulk order. It depends on the actual shipping situation. |
Hot Tags: ball screw linear module x y z axial, China, suppliers, manufacturers, factory, customized, wholesale, price, free sample
