Miniature Linear Guide MGN

The MG series is a miniature linear guide way that comes in a compact size with a Gothic arch contact design that offers high stiffness and high rigidity against moment loads in all directions. The MG series also offers anti-corrosion protection which all material is in a special grade of stainless steel for compatibility in various working environments. The MG series is available in a narrow block type (MGN) and also with an enlarged width (MGW).

Send Inquiry

Product Introduction

Description

The MGN Series range of miniature linear guides & carriages, including rolling balls and ball retainers, are manufactured from a special grade of stainless steel for anti-corrosion purpose. The gothic arch contact design can sustain loads from all directions and offer high rigidity and accuracy. Internally the steel balls are held by means of a miniature retainer to keep away from balls from falling out, even when the blocks are removed from the rail for installation.

Features of MGN Series

1. Tiny and light weight, suitable for miniature equipment.

2. All materials for block and rail, including rolling balls and ball retainers, are in special grade of stainless steel for anti-corrosion purpose.

3. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.

4. Steel balls will be held by miniature retainer to avoid balls from falling out even when the blocks are removed from the rail installation.

5. Interchangeable types are available in certain precision grades.

Product Details

MGN and MGW series linear guides are miniature guide rails, which the width, height and length are smaller than normal series. They are broadly use in small precision machines, such as 3d printers.

Product name	Miniature Linear Guideway
Application	linear motion system
Feature	Smooth Motion
Block Type	Suqare block
Certificate	ISO9001/CE
Lubrication	Oil
Bussiness Nature	Manufacturer
