Stepper Motor Bracket

Integrated motor mount positioning holes and the fixed bearing end support block mounting hole take the integrated processing, to ensure motor shaft, coupling axial, axial bearing hole, and ball screw axis all in a line strictly, make the ball screw kit and the transmission machine run greater accurately, less noise and longer life.

Send Inquiry

Product Introduction

Stepper Motor Bracket

Product Description

a. Easy to install and use. The bearing seat and the motor seat are processed in one piece, and they are directly based after installation, eliminating the need for adjustment steps.

b. Strict shape and position tolerances, and all shape and position tolerances of the overall ending are strictly controlled.

c. The technical status is steady and interchangeable.

d. High rigidity and strong impact resistance.

product-800-1104

Product Information
Product Name	Stepper Motor Bracket
Material	Aluminum alloy motor mount bracket
Advantages	1. Simple installation: equipped with a unit, the motor can be easily installed using the connector. 2. High precision: The ball screw and the mounting part of the motor are integrated. This structure can effectively reduce the error between the two shafts. 3. High positioning accuracy: The connecting piece is equipped with a special ball screw support seat, which can effectively control the axial movement of the screw. 4. High rigidity: The connecting parts are made of high-quality medium carbon steel, which has strong impact resistance and durability.
Model No.	BC12ZC/AC-57, BC12ZC/AC-60, BC15ZC/AC-80, BC15ZC/AC-86
Size Available	Nema23,Nema34 stepper motor, and 60/80 servo motor
Product Package	a. Plastic bag with box case or wooden case. b. According to our customer's request. We can provide shipping information to our customer at any time.
Delivery Time	3~5 days for sample order, 7~10 days for small order, 10~20 days for bulk order. It depends on the actual shipping situation.
